| 3800 Series II Supercharged V-6 |
|
| 3800 Series II
Supercharged V-6 |
|
| Type | 90o V-6 |
|
| Bore and Stroke (in.) | 3.80 x 3.40 |
|
| Piston Displacement (cu. in.) | 231 |
|
| Cylinder Head and Block Material | Cast Iron/Cast Iron |
|
| Compression Ratio | 8.5:1 |
|
| Net Horsepower @ Engine rpm | 240 @ 5200 |
|
| Net Torque (lbs-ft) @ Engine rpm | 280 @ 3600 |
|
| Recommended Fuel | Unleaded Premium |
|
| Fuel Management | Supercharged Sequential-Port Fuel Injection |
|
| Oil Capacity (qts) | 4 (5 w/filter) |
|
| EPA Fuel Economy Rating, City/Hwy (Projected) | 18/27 |
|
| Suspension |
|
| Front Suspension Type | MacPherson Strut |
|
| Shock Absorbers, Front | Deflected Disc Strut |
|
| Stabilizer (mm) | 28 mm - Tube |
|
| Rear Suspension Type | Semi-Trailing Arm |
|
| Shock Absorbers, Rear | Twin Tube with Electronic Level Control |
|
| Transaxle |
|
| Automatic Transmission with Overdrive |
|
| Type | Four-Speed with Electronically Controlled Capacity Clutch |
|
| Selector Pattern | PRND321 |
|
| Gear Ratio (each times converter ratio) |
|
| First | 2.92 |
|
| Second | 1.57 |
|
| Third | 1.00 |
|
| Fourth | 0.71 |
|
| Reverse | 2.39 |
|
| Final Drive Ratio | 2.93 |
|
| Cooling | Liquid |
|
| Capacity - Dry (pts) | 26.8 |
|
| Chassis |
|
| Chassis/Body | Integral Frame Body |
|
| Body Material | Steel |
|
| Steering |
|
| Steering Gear Type | Rack-and-Pinion |
|
| Overall Ratio | Variable 15.5:1 to 13.5:1 |
|
| Number of Wheel Turns (stop to stop) | 3.15 |
|
| Turning Diameter (ft) (curb to curb) | 39.1L/39.1R |
|
| Linkage | Rear |
|
| Tie Rods, Number | 2 |
|
| Parking Brake |
|
| Control | Foot Pedal |
|
| Operated On | Rear Brakes |
|
| Operation | Push-to-Set-and-Release |
|
| Release Location | Left-Hand Side Under Instrument Panel |
|
| Key Features |
|
| Powertrain/Chassis/Suspension: |
| -- 3800 SFI Series Supercharged V-6 |
| -- New 125-amp generator w/dual tangential mounted altenator |
| -- Heavy-duty electronically controlled 4-speed automatic transmission |
| -- Power 4-wheel anto-lock brake system |
| -- Magnetic variable effort steering |
| -- Full-range traction control system |
|
| Exterior: |
| Four new exterior colors: Sterling Silver Metallic (12), Titanium Blue Metallic
(Feb. 1999)(55), Gold Firemist Metallic (60) and Dark Bronzemist Metallic (76) |
| -- 16" wheels and tires |
| -- Daytime running lamps with Twilight Sentinel® |
| -- Remote keyless entry |
|
| Interior: |
| -- Interior Convenience Plus Features |
| -- Remote-controlled outside rearview mirrors, heated |
| -- Dual ComforTemp climate control system with rear-seat ComforTemp |
| -- Leather-wrapped steering wheel |
| -- 6-way power front bucket seats |
|
| New Standard Equipment: |
| -- Full-range traction control system |
|
| Sound System: |
| -- ETR® AM-FM stereo combination cassette/CD players with automatic tone control (UP0) |
|
| Convenience Plus Features: |
| Include electronic reminder tones for ignition key, headlamps, turn signals,
parking brake "on"; delayed entry and exit lighting, theater dimming, Battery Rundown Protection,
lock-out protection, delayed locking, flash-to-pass signal, PASS-Key® II passive theft-deterrent
system, daytime running lamps with Twilight Sentinel®, retained accessory power and auxiliary
power outlet. |
|
| Brakes |
|
| Power Brake Type | Power Four-Wheel Disc
Anti-Lock System |
|
| Self-Adjusting Feature | Standard |
|
| Hydraulic System Type | Proportioning |
|
| Effective Area Total (sq. in.) | 40.9 |
|
| Gross Lining Area Total (sq. in.) | 52.7 |
|
| Swept Area Total (sq. in.) | 397.9 |
|
| Rotor Diameter (in.) (F/R) | 11.85/10.94 |
|
| Rotor Thickness (in.) (F/R) | 1.26/.43 |
|
| Rotor Material and Type (F) | Cast Iron - Vented |
|
| (R) | Cast Iron - Solid |
|
| Brake Lining Material |
| Front and Rear | Nonasbestos Organic |
|
| Front Lining |
| Outboard (in.) | 4.96 x 1.85 x .50 |
| Inboard (in.) | 4.96 x 1.85 x .50 |
|
| Rear Lining |
| Outboard (in.) | 3.57 x 1.33 x .35 |
| Inboard (in.) | 3.57 x 1.33 x .35 |
