| 3800 Series II Supercharged V-6 |
|
| 3800 Series II V-6
(Std.) (Park Avenue) | Series II Supercharged 3800 V-6 (Std.) (Ultra) |
|
| Type | 90o V-6 | 90o V-6 |
|
| Bore and Stroke (in.) | 3.80 x 3.40 | 3.80 x 3.40 |
|
| Piston Displacement (cu. in.) | 231 | 231 |
|
| Cylinder Head and Block Material | Cast Iron/Cast Iron | Cast Iron/Cast Iron |
|
| Compression Ratio | 9.4:1 | 8.5:1 |
|
| Net Horsepower @ Engine rpm | 205 @ 5200 | 240 @ 5200 |
|
| Net Torque (lbs-ft) @ Engine rpm | 230 @ 4000 | 280 @ 3600 |
|
| Recommended Fuel | Unleaded Regular | Unleaded Premium |
|
| Fuel Management | Sequential-Port Fuel Injection | Supercharged Sequential-Port Fuel Injection |
|
| Oil Capacity (qts) | 4 (5 w/filter) | 4 (5 w/filter) |
|
| EPA Fuel Economy Rating, City/Hwy (Projected) | 19/28 | 18/27 |
|
| Steering |
|
| Steering Gear Type (Park Avenue) | Power Rack and Pinion |
|
| Steering Gear Type (Ultra) | Magnetic Variable Effort |
|
| Overall Ratio | 17.0:1/15.4:1 |
|
| Number of Wheel Turns (stop to stop) | 2.93/3.15** |
|
| Turning Diameter (ft) (curb to curb) (L/R) | 39.4/40.0 |
|
| Linkage | Rear |
|
| Tie Rods, Number | 2 |
|
| **Ultra and Y56 package |
|
| Transaxle |
|
| Automatic Transmission with Overdrive |
|
| Type | Four-Speed with Electronically Controlled Capacity Clutch |
|
| Selector Pattern | PRNDD21 |
|
| Gear Ratio (each times converter ratio) |
|
| First | 2.92 |
|
| Second | 1.57 |
|
| Third | 1.00 |
|
| Fourth | 0.70 |
|
| Reverse | 2.39 |
|
| Final Drive Ratio | 3.05/2.93* |
|
| Cooling | Liquid |
|
| Capacity - Dry (pts) | 14.8 |
|
| *Ultra |
|
| Brakes |
|
| Power Brake Type | Power Front Disc/Rear Disc Anti-Lock System |
|
| Self-Adjusting Feature | Standard |
|
| Hydraulic System Type | Proportioning |
|
| Effective Area Total (sq. in.) | 40.9 |
|
| Gross Lining Area Total (sq. in.) | 52.7 |
|
| Swept Area Total (sq. in.) | 397.9 |
|
| Rotor Diameter/Thickness (in.) | Front:11.85/1.26
Rear: 10.94/.43 |
|
| Rotor Material and Type (F/R) | Cast Iron - Vented
Cast Iron - Solid |
|
| Brake Lining Material, Front and Rear | Semi-Metallic |
|
Front Lining
Outboard (in.)
Inboard (in.) | 4.96 x 1.85 x .50
4.96 x 1.85 x .50 |
|
Rear Lining
Outboard (in.)
Inboard (in.) | 3.57 x 1.33 x .35
3.57 x 1.33 x .35 |
|
| Suspension |
|
| Front Suspension Type | MacPherson Strut |
|
| Shock Absorbers, Front | Deflected Disc Strut |
|
| Stabilizer (mm) | 30 mm - Solid Bar |
|
| Rear Suspension Type | Semi-Trailing w/Lateral Link |
|
| Shock Absorbers | Twin Tube with Electronic Level Control |
|
| Key Features |
|
| Powertrain/Chassis/Suspension: |
-- 3800 SFI Series II V-6
-- 3800 SFI Series II Supercharged V-6 (Ultra)
-- Power 4-wheel anti-lock disc brake system
-- Automatic level control
-- Heavy duty battery (standard on Ultra) |
|
| Exterior: |
-- Five new exterior colors: Sterling Silver Metallic (12), Titanium Blue Metallic (Feb. 1999) (55),
Gold Firemist (60), Dark Bronzemist (76) and Bright White Diamond (late 1998)
-- Michelin tires standard (base Ultra)
-- New improved tail lamp appearance (late 1998)
-- Hood to fender seal modified to improve appearance
-- New adjustable deck lid rubber bumper
|
|
| Interior: |
-- Driver Information Center (Standard on Ultra, optional on Park Avenue)
-- Interior Convenience Plus features
-- 10-way power seats
-- Dual automatic ComforTemp climate control
-- New instrument panel and door trim-plates
-- PASS-Key® III theft-deterrent system
-- Remote keyless entry
-- Inside rearview electrochromic mirror with compass (standard on Ultra, optional on Park Avenue)
|
|
| Sound System: New enhanced Concert Sound III: |
-- Nine-speakers and customer equalized amplifier
-- Front doors each have a tweeter and a mid-range speaker
-- Front center dash and rear doors have mid-range speakers
-- Rear package shelf has two 6 x 9 subwoofers
-- Amplifier package is located under rear package shelf
-- Rear window integrated antenna system
|
