| 3100 SFI V-6 |
|
| Type | 60o V-6 |
|
| Bore and Stroke (in.) | 3.51 x 3.31 |
|
| Piston Displacement (cu. in.) | 191 |
|
| Cylinder Head and Block Material | Cast Aluminum/Cast Iron |
|
| Compression Ratio | 9.6:1 |
|
| Net Horsepower @ Engine rpm | 160 @ 5200 |
|
| Net Torque (lbs-ft) @ Engine rpm | 185 @ 4000 |
|
| Recommended Fuel | Unleaded Regular |
|
| Fuel Management | Sequential-Port Fuel Injection |
|
| Oil Capacity (qts) | 4 (5 w/filter) |
|
| EPA Fuel Economy Rating, |
| City/Hwy (Projected) | 20/29 |
|
| Transaxle |
|
| Automatic Transmission with Overdrive |
|
| Type | Four-Speed with Electronically Controlled
Capacity Clutch |
|
| Selector Pattern | PRND321 |
|
| Gear Ratio (each times converter ratio) |
|
| First | 2.92 |
|
| Second | 1.57 |
|
| Third | 1.00 |
|
| Fourth | 0.70 |
|
| Reverse | 2.38 |
|
| Final Drive Ratio | 3.29 |
|
| Cooling | Liquid |
|
| Capacity - Dry (pts) | 26.8 |
|
| Suspension |
|
| Front Suspension Type | MacPherson Strut with L-Shaped Lower Control Arm and Aluminum Knuckle |
|
| Shock Absorbers | Twin-tube strut |
|
| Stabilizer (in.) | 1.18 |
|
| Rear Suspension Type | Isolated, Independent, Coil Over Strut, Tri-Link Design |
|
| Shock Absorbers | Twin-Tube Strut |
|
| Stabilizer (in.) | .55 (Solid) |
|
| Chassis |
|
| Chassis/Body | Integral Body/Frame Construction |
|
| Body Material | Steel |
|
| Key Features |
|
| Powertrain/Chassis/Suspension: |
| -- 3100 SFI-V6 |
| -- Revised accessory drive belt |
| -- New enhanced anti-lock brake system |
| -- Revised suspension system |
|
| Exterior: |
| -- One new exterior color: Auburn Nightmist Pearl (52) |
| -- Mirrors outside - Dual remote power, folding rearview |
| -- Daytime running lamps |
| -- Trunk - 16.7 cubic feet with low lift-over |
|
| Interior: |
| -- Battery Rundown Protection |
| -- Armrest front seat storage with dual cup holder |
| -- Theater seating |
| -- Remote keyless entry |
| -- PASS-Key® theft-deterrent system |
| -- Air filtration system |
| -- Power, memory door locks with lock-out protection |
| -- Power windows with express-down feature |
|
| New Standard Equipment: |
| -- Concert Sound II |
| -- Tire inflation monitor |
| -- Enhanced traction control system |
|
| Product Improvements: |
| -- Enhanced efficiency HVAC fan motor |
| -- Electrochromic outside rearview mirror (optional) |
|
| Sound System (optional): New Concert Sound III |
| -- Eight speakers: Two 6 x 9 subwoofers (package shelf),
four right and four left mid-range satellites (two on front doors and two
in package shelf) and two tweeters (front doors) |
| -- Customer-equalizable amplifier located below rear package shelf. |
| -- Improved reception performance via new diversity antenna. |
|
| Brakes |
|
| Power Brake Type | Power Front Disc/Rear Drum
Four-Wheel Anti-Lock System |
|
| Self-Adjusting Feature | Standard |
|
| Hydraulic System Type | Split Diagonal |
|
| Effective Area Total (sq. in.) | 98.9 |
|
| Gross Lining Area Total (sq. in.) | 96.2 |
|
| Swept Area Total (sq. in.) | 306.8 |
|
| Rotor Diameter (in.)(outer) | 7.1/10.8 |
|
| Rotor Thickness (in.) | 1.3 |
|
| Rotor Material and Type | Cast Iron - Vented |
|
| Drum Material and Type | Cast Iron - Finned |
|
| Brake Lining Material, |
| Front and Rear | Nonasbestos Semi-Metallic |
|
| Front Lining |
| Outboard (in.) | 4.96 x 1.81 x .60 |
| Inboard (in.) | 4.96 x 1.81 x .60 |
|
| Rear Lining |
| Outboard (in.) | 8.85 x 1.73 x .25 |
| Inboard (in.) | 8.85 x 1.73 x .25 |
|
| Steering |
|
| Steering Gear Type | Rack-and-Pinion |
|
| Overall Ratio | 16.8:1 |
|
| Number of Wheel Turns (stop to stop) | 3.04 |
|
| Turning Diameter (ft) (curb to curb) | 37.5 |
|
| Linkage | Rear |
|
| Tie Rods, Number | 2 |
|
| Parking Brake |
|
| Control | Foot Pedal |
|
| Operated On | Rear Brakes |
|
| Operation | Push-to-Set-and-Release |
|
| Release Location | Left of Driver's Left Knee |
